ESP-01S打造的最具性价比的esphome终端

nameryan · 发表于 2019-10-22 11:01:39

折腾了那么久的家居智能，前后用过小米的wifi开关，控客的小K系列，不知名的智能插座，以及廉价版的Sonoff等等，前阵子捣鼓esphome，总结出一套性价比非常高的wifi开关方案。

一句话就是通过ESP-01S，烧ESPHOME固件来控制继电器开关。

看看下面主要设备ESP-01S的价格：

再加上220v-3.3v的电源隔离开关以及继电器，成本控制在15元应该不是问题，这样就适合大规模的改装了。

如果改装的是已经有3.3v电源，或者不需要继电器，可以gpio直接控制的设备，那么一个esp-01s就足以撑起整个改装，成本就是6.4元。

分析了成本和方案，接下来要讲讲技术活了。

登录/注册后可看大图

▍ESP-01与ESP-01S的区别

ESP01-S实际上是大名鼎鼎的ESP8266的简配版，Sonoff开关用的就是这款芯片。

淘宝搜索的话，还会发现有esp-01和esp-01s两种型号，具体区别如下：

外观区别1：ESP8266-01S天线区域右下角只有一个指示灯，ESP8266-01天线区域右下角有两个指示灯。

外观区别2：ESP8266-01S背面有引脚说明，ESP8266-01背面有没有引脚说明。
内部区别：ESP8266-01S内部电路相对应ESP8266-01做了优化，使用建议大家购买的时候买ESP8266-01S

▍ESP-01S接线

可以看到，esp01-s在烧写程序的时候，需要将gpio0接地，ch-pd拉高，烧写完以后，再恢复正常使用。这点比直接用Sonoff开关麻烦。

同时因为有两个gpio可以使用，理论上也可以接两个继电器，做成一个双模的wifi开关。

▍ESPHOME控制代码

最后再上一段esphome中的代码，实现了定时开启关闭和button控制继电器的功能。

esphome:
  name: esp01s_1
  platform: ESP8266
  board: esp01_1m

wifi:
  ssid: "你的wifi ssid"
  password: "你的wifi密码"

api:

logger:

ota:

#设置定时开启和关闭
time:
  - platform: homeassistant
    on_time:
      # Every time on weekdays and weekends
      - seconds: 0
        minutes: 0
        hours: 0
        days_of_week: MON-SUN
        then:
          - switch.turn_on: relay

      - seconds: 0
        minutes: 0
        hours: 4
        days_of_week: MON-SUN
        then:
          - switch.turn_off: my_switch

#按键
binary_sensor:
  - platform: gpio
    pin:
      number: GPIO0
      mode: INPUT_PULLUP
      inverted: True
    name: "Sonoff Basic Button"
    on_press:
      - switch.toggle: my_switch

switch:
  - platform: gpio
    name: "Sonoff Basic Relay"
    pin: GPIO2
    id: my_switch

status_led:
  pin:
    number: GPIO13
    inverted: yes

扫码关注公众号，获取更多智能家居改装技能。

602293544 · 发表于 2019-10-22 11:18:27

rx tx不是也可以用吗

natic · 发表于 2019-10-22 11:20:38

602293544 发表于 2019-10-22 11:18
rx tx不是也可以用吗

理论上可以使用，但是esp01的大部分针脚都要特别注意针脚定义，免得用起来遇到奇怪的问题

lighu36 · 发表于 2019-10-22 13:13:43

先收藏了装修好再弄

sup3rsky · 发表于 2019-10-22 13:31:25

本帖最后由 sup3rsky 于 2019-10-22 13:33 编辑

01s启动时gpio0接地也是启动不了的吧？手上有个01的继电器模块，就是这种情况，自己改成了gpio2控制继电器

nameryan · 发表于 2019-10-22 14:14:40

sup3rsky 发表于 2019-10-22 13:31
01s启动时gpio0接地也是启动不了的吧？手上有个01的继电器模块，就是这种情况，自己改成了gpio2控制继电器 ...

没试过gpio0接继电器，我代码里gpio0对应的是button按键，跟sonoff设计的一样。
用gpio2来控制继电器。
理论上还可以用rx、tx来控制继电器，这么看来是不是可以一下子控制好几个继电器了？

netsnake · 发表于 2019-10-22 17:20:08

01s用起来更方便！

搭车问下：

今天手快清除了esphome一个项目的旧build，然后重新编译，老是报link错误，说有重复定义。版本1.13.6，不知各位遇到这个问题没有，如何解决？
项目很简单，就是定义了两个fastled灯！

nameryan · 发表于 2019-10-22 17:49:33

netsnake 发表于 2019-10-22 17:20
01s用起来更方便！

搭车问下：

代码和报错信息具体贴出来看看吧，话题延展一下

netsnake · 发表于 2019-10-23 10:12:19

nameryan 发表于 2019-10-22 17:49
代码和报错信息具体贴出来看看吧，话题延展一下

编译错误内容：

Compiling .pioenvs/light_led_8/FrameworkArduino/umm_malloc/umm_malloc.c.o
Archiving .pioenvs/light_led_8/libFrameworkArduino.a
Linking .pioenvs/light_led_8/firmware.elf
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncClient::_s_recv(void*, tcp_pcb*, pbuf*, long)':
ESPAsyncTCP.cpp:(.text._ZN11AsyncClient7_s_recvEPvP7tcp_pcbP4pbufl+0x4): multiple definition of `AsyncClient::_s_recv(void*, tcp_pcb*, pbuf*, long)'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncClient7_s_recvEPvP7tcp_pcbP4pbufl+0x10): first defined here
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncClient::_s_sent(void*, tcp_pcb*, unsigned short)':
ESPAsyncTCP.cpp:(.text._ZN11AsyncClient7_s_sentEPvP7tcp_pcbt+0x4): multiple definition of `AsyncClient::_s_sent(void*, tcp_pcb*, unsigned short)'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncClient7_s_sentEPvP7tcp_pcbt+0x10): first defined here
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncClient::_s_error(void*, long)':
ESPAsyncTCP.cpp:(.text._ZN11AsyncClient8_s_errorEPvl+0x4): multiple definition of `AsyncClient::_s_error(void*, long)'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncClient8_s_errorEPvl+0xc): first defined here
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncClient::_s_poll(void*, tcp_pcb*)':
ESPAsyncTCP.cpp:(.text._ZN11AsyncClient7_s_pollEPvP7tcp_pcb+0x4): multiple definition of `AsyncClient::_s_poll(void*, tcp_pcb*)'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncClient7_s_pollEPvP7tcp_pcb+0x10): first defined here
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncClient::AsyncClient(tcp_pcb*)':
ESPAsyncTCP.cpp:(.text._ZN11AsyncClientC2EP7tcp_pcb+0x30): multiple definition of `AsyncClient::AsyncClient(tcp_pcb*)'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncClientC2EP7tcp_pcb+0x48): first defined here
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncClient::AsyncClient(tcp_pcb*)':
ESPAsyncTCP.cpp:(.text._ZN11AsyncClientC2EP7tcp_pcb+0x30): multiple definition of `AsyncClient::AsyncClient(tcp_pcb*)'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncClientC2EP7tcp_pcb+0x48): first defined here
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncClient::_s_connected(void*, void*, long)':
ESPAsyncTCP.cpp:(.text._ZN11AsyncClient12_s_connectedEPvS0_l+0x4): multiple definition of `AsyncClient::_s_connected(void*, void*, long)'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncClient12_s_connectedEPvS0_l+0x10): first defined here
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncClient::connect(IPAddress, unsigned short)':
ESPAsyncTCP.cpp:(.text._ZN11AsyncClient7connectE9IPAddresst+0x18): multiple definition of `AsyncClient::connect(IPAddress, unsigned short)'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncClient7connectE9IPAddresst+0x1c): first defined here
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncClient::_s_dns_found(char const*, ip_addr const*, void*)':
ESPAsyncTCP.cpp:(.text._ZN11AsyncClient12_s_dns_foundEPKcPK7ip_addrPv+0x4): multiple definition of `AsyncClient::_s_dns_found(char const*, ip_addr const*, void*)'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncClient12_s_dns_foundEPKcPK7ip_addrPv+0x4): first defined here
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncClient::connect(char const*, unsigned short)':
ESPAsyncTCP.cpp:(.text._ZN11AsyncClient7connectEPKct+0x10): multiple definition of `AsyncClient::connect(char const*, unsigned short)'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncClient7connectEPKct+0x10): first defined here
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncClient::operator==(AsyncClient const&)':
ESPAsyncTCP.cpp:(.text._ZN11AsyncClienteqERKS_+0x0): multiple definition of `AsyncClient::operator==(AsyncClient const&)'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncClienteqERKS_+0x0): first defined here
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncClient::abort()':
ESPAsyncTCP.cpp:(.text._ZN11AsyncClient5abortEv+0x4): multiple definition of `AsyncClient::abort()'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncClient5abortEv+0x4): first defined here
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncClient::free()':
ESPAsyncTCP.cpp:(.text._ZN11AsyncClient4freeEv+0x4): multiple definition of `AsyncClient::free()'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncClient4freeEv+0x4): first defined here
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncClient::send()':
ESPAsyncTCP.cpp:(.text._ZN11AsyncClient4sendEv+0x8): multiple definition of `AsyncClient::send()'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncClient4sendEv+0x8): first defined here
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncClient::ack(unsigned int)':
ESPAsyncTCP.cpp:(.text._ZN11AsyncClient3ackEj+0x4): multiple definition of `AsyncClient::ack(unsigned int)'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncClient3ackEj+0x4): first defined here
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncClient::operator+=(AsyncClient const&)':
ESPAsyncTCP.cpp:(.text._ZN11AsyncClientpLERKS_+0x0): multiple definition of `AsyncClient::operator+=(AsyncClient const&)'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncClientpLERKS_+0x0): first defined here
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncClient::setRxTimeout(unsigned int)':
ESPAsyncTCP.cpp:(.text._ZN11AsyncClient12setRxTimeoutEj+0x0): multiple definition of `AsyncClient::setRxTimeout(unsigned int)'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncClient12setRxTimeoutEj+0x0): first defined here
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncClient::getRxTimeout()':
ESPAsyncTCP.cpp:(.text._ZN11AsyncClient12getRxTimeoutEv+0x0): multiple definition of `AsyncClient::getRxTimeout()'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncClient12getRxTimeoutEv+0x0): first defined here
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncClient::getAckTimeout()':
ESPAsyncTCP.cpp:(.text._ZN11AsyncClient13getAckTimeoutEv+0x0): multiple definition of `AsyncClient::getAckTimeout()'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncClient13getAckTimeoutEv+0x0): first defined here
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncClient::setAckTimeout(unsigned int)':
ESPAsyncTCP.cpp:(.text._ZN11AsyncClient13setAckTimeoutEj+0x0): multiple definition of `AsyncClient::setAckTimeout(unsigned int)'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncClient13setAckTimeoutEj+0x0): first defined here
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncClient::setNoDelay(bool)':
ESPAsyncTCP.cpp:(.text._ZN11AsyncClient10setNoDelayEb+0x0): multiple definition of `AsyncClient::setNoDelay(bool)'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncClient10setNoDelayEb+0x0): first defined here
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncClient::getNoDelay()':
ESPAsyncTCP.cpp:(.text._ZN11AsyncClient10getNoDelayEv+0x0): multiple definition of `AsyncClient::getNoDelay()'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncClient10getNoDelayEv+0x0): first defined here
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncClient::getMss()':
ESPAsyncTCP.cpp:(.text._ZN11AsyncClient6getMssEv+0x0): multiple definition of `AsyncClient::getMss()'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncClient6getMssEv+0x0): first defined here
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncClient::getRemoteAddress()':
ESPAsyncTCP.cpp:(.text._ZN11AsyncClient16getRemoteAddressEv+0x0): multiple definition of `AsyncClient::getRemoteAddress()'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncClient16getRemoteAddressEv+0x0): first defined here
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncClient::getRemotePort()':
ESPAsyncTCP.cpp:(.text._ZN11AsyncClient13getRemotePortEv+0x0): multiple definition of `AsyncClient::getRemotePort()'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncClient13getRemotePortEv+0x0): first defined here
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncClient::getLocalAddress()':
ESPAsyncTCP.cpp:(.text._ZN11AsyncClient15getLocalAddressEv+0x0): multiple definition of `AsyncClient::getLocalAddress()'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncClient15getLocalAddressEv+0x0): first defined here
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncClient::getLocalPort()':
ESPAsyncTCP.cpp:(.text._ZN11AsyncClient12getLocalPortEv+0x0): multiple definition of `AsyncClient::getLocalPort()'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncClient12getLocalPortEv+0x0): first defined here
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncClient::remoteIP()':
ESPAsyncTCP.cpp:(.text._ZN11AsyncClient8remoteIPEv+0x8): multiple definition of `AsyncClient::remoteIP()'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncClient8remoteIPEv+0x8): first defined here
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncClient::remotePort()':
ESPAsyncTCP.cpp:(.text._ZN11AsyncClient10remotePortEv+0x4): multiple definition of `AsyncClient::remotePort()'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncClient10remotePortEv+0x4): first defined here
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncClient::localIP()':
ESPAsyncTCP.cpp:(.text._ZN11AsyncClient7localIPEv+0x8): multiple definition of `AsyncClient::localIP()'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncClient7localIPEv+0x8): first defined here
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncClient::localPort()':
ESPAsyncTCP.cpp:(.text._ZN11AsyncClient9localPortEv+0x4): multiple definition of `AsyncClient::localPort()'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncClient9localPortEv+0x4): first defined here
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncClient::state()':
ESPAsyncTCP.cpp:(.text._ZN11AsyncClient5stateEv+0x0): multiple definition of `AsyncClient::state()'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncClient5stateEv+0x0): first defined here
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncClient::connected()':
ESPAsyncTCP.cpp:(.text._ZN11AsyncClient9connectedEv+0x0): multiple definition of `AsyncClient::connected()'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncClient9connectedEv+0x0): first defined here
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncClient::connecting()':
ESPAsyncTCP.cpp:(.text._ZN11AsyncClient10connectingEv+0x0): multiple definition of `AsyncClient::connecting()'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncClient10connectingEv+0x0): first defined here
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncClient::disconnecting()':
ESPAsyncTCP.cpp:(.text._ZN11AsyncClient13disconnectingEv+0x0): multiple definition of `AsyncClient::disconnecting()'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncClient13disconnectingEv+0x0): first defined here
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncClient::disconnected()':
ESPAsyncTCP.cpp:(.text._ZN11AsyncClient12disconnectedEv+0x0): multiple definition of `AsyncClient::disconnected()'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncClient12disconnectedEv+0x0): first defined here
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncClient::freeable()':
ESPAsyncTCP.cpp:(.text._ZN11AsyncClient8freeableEv+0x4): multiple definition of `AsyncClient::freeable()'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncClient8freeableEv+0x4): first defined here
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncClient::space()':
ESPAsyncTCP.cpp:(.text._ZN11AsyncClient5spaceEv+0x0): multiple definition of `AsyncClient::space()'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncClient5spaceEv+0x0): first defined here
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncClient::add(char const*, unsigned int, unsigned char)':
ESPAsyncTCP.cpp:(.text._ZN11AsyncClient3addEPKcjh+0x8): multiple definition of `AsyncClient::add(char const*, unsigned int, unsigned char)'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncClient3addEPKcjh+0x8): first defined here
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncClient::write(char const*, unsigned int, unsigned char)':
ESPAsyncTCP.cpp:(.text._ZN11AsyncClient5writeEPKcjh+0x8): multiple definition of `AsyncClient::write(char const*, unsigned int, unsigned char)'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncClient5writeEPKcjh+0x8): first defined here
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncClient::write(char const*)':
ESPAsyncTCP.cpp:(.text._ZN11AsyncClient5writeEPKc+0x8): multiple definition of `AsyncClient::write(char const*)'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncClient5writeEPKc+0x8): first defined here
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncClient::canSend()':
ESPAsyncTCP.cpp:(.text._ZN11AsyncClient7canSendEv+0x4): multiple definition of `AsyncClient::canSend()'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncClient7canSendEv+0x4): first defined here
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncClient::ackPacket(pbuf*)':
ESPAsyncTCP.cpp:(.text._ZN11AsyncClient9ackPacketEP4pbuf+0x8): multiple definition of `AsyncClient::ackPacket(pbuf*)'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncClient9ackPacketEP4pbuf+0x8): first defined here
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncClient::stateToString()':
ESPAsyncTCP.cpp:(.text._ZN11AsyncClient13stateToStringEv+0xc): multiple definition of `AsyncClient::stateToString()'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncClient13stateToStringEv+0xc): first defined here
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncServer::AsyncServer(IPAddress, unsigned short)':
ESPAsyncTCP.cpp:(.text._ZN11AsyncServerC2E9IPAddresst+0x4): multiple definition of `AsyncServer::AsyncServer(IPAddress, unsigned short)'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncServerC2E9IPAddresst+0x4): first defined here
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncServer::AsyncServer(IPAddress, unsigned short)':
ESPAsyncTCP.cpp:(.text._ZN11AsyncServerC2E9IPAddresst+0x4): multiple definition of `AsyncServer::AsyncServer(IPAddress, unsigned short)'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncServerC2E9IPAddresst+0x4): first defined here
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncServer::AsyncServer(unsigned short)':
ESPAsyncTCP.cpp:(.text._ZN11AsyncServerC2Et+0x4): multiple definition of `AsyncServer::AsyncServer(unsigned short)'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncServerC2Et+0x4): first defined here
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncServer::AsyncServer(unsigned short)':
ESPAsyncTCP.cpp:(.text._ZN11AsyncServerC2Et+0x4): multiple definition of `AsyncServer::AsyncServer(unsigned short)'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncServerC2Et+0x4): first defined here
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncServer::_s_accept(void*, tcp_pcb*, long)':
ESPAsyncTCP.cpp:(.text._ZN11AsyncServer9_s_acceptEPvP7tcp_pcbl+0x4): multiple definition of `AsyncServer::_s_accept(void*, tcp_pcb*, long)'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncServer9_s_acceptEPvP7tcp_pcbl+0x4): first defined here
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncServer::begin()':
ESPAsyncTCP.cpp:(.text._ZN11AsyncServer5beginEv+0x1c): multiple definition of `AsyncServer::begin()'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncServer5beginEv+0x20): first defined here
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncServer::end()':
ESPAsyncTCP.cpp:(.text._ZN11AsyncServer3endEv+0x10): multiple definition of `AsyncServer::end()'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncServer3endEv+0x10): first defined here
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncServer::~AsyncServer()':
ESPAsyncTCP.cpp:(.text._ZN11AsyncServerD2Ev+0x8): multiple definition of `AsyncServer::~AsyncServer()'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncServerD2Ev+0x8): first defined here
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncServer::~AsyncServer()':
ESPAsyncTCP.cpp:(.text._ZN11AsyncServerD2Ev+0x8): multiple definition of `AsyncServer::~AsyncServer()'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncServerD2Ev+0x8): first defined here
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncServer::setNoDelay(bool)':
ESPAsyncTCP.cpp:(.text._ZN11AsyncServer10setNoDelayEb+0x0): multiple definition of `AsyncServer::setNoDelay(bool)'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncServer10setNoDelayEb+0x0): first defined here
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncServer::getNoDelay()':
ESPAsyncTCP.cpp:(.text._ZN11AsyncServer10getNoDelayEv+0x0): multiple definition of `AsyncServer::getNoDelay()'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncServer10getNoDelayEv+0x0): first defined here
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncServer::status()':
ESPAsyncTCP.cpp:(.text._ZN11AsyncServer6statusEv+0x0): multiple definition of `AsyncServer::status()'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncServer6statusEv+0x0): first defined here
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncClient::_close()':
ESPAsyncTCP.cpp:(.text._ZN11AsyncClient6_closeEv+0x20): multiple definition of `AsyncClient::_close()'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncClient6_closeEv+0x10): first defined here
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncClient::~AsyncClient()':
ESPAsyncTCP.cpp:(.text._ZN11AsyncClientD2Ev+0x24): multiple definition of `AsyncClient::~AsyncClient()'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncClientD2Ev+0x28): first defined here
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncClient::~AsyncClient()':
ESPAsyncTCP.cpp:(.text._ZN11AsyncClientD2Ev+0x24): multiple definition of `AsyncClient::~AsyncClient()'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncClientD2Ev+0x28): first defined here
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncClient::operator=(AsyncClient const&)':
ESPAsyncTCP.cpp:(.text._ZN11AsyncClientaSERKS_+0x30): multiple definition of `AsyncClient::operator=(AsyncClient const&)'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncClientaSERKS_+0x34): first defined here
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncClient::close(bool)':
ESPAsyncTCP.cpp:(.text._ZN11AsyncClient5closeEb+0x8): multiple definition of `AsyncClient::close(bool)'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncClient5closeEb+0x8): first defined here
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncClient::stop()':
ESPAsyncTCP.cpp:(.text._ZN11AsyncClient4stopEv+0x4): multiple definition of `AsyncClient::stop()'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncClient4stopEv+0x4): first defined here
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncServer::_accept(tcp_pcb*, long)':
ESPAsyncTCP.cpp:(.text._ZN11AsyncServer7_acceptEP7tcp_pcbl+0x14): multiple definition of `AsyncServer::_accept(tcp_pcb*, long)'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncServer7_acceptEP7tcp_pcbl+0x24): first defined here
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncClient::_error(long)':
ESPAsyncTCP.cpp:(.text._ZN11AsyncClient6_errorEl+0x18): multiple definition of `AsyncClient::_error(long)'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncClient6_errorEl+0x4): first defined here
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncClient::_dns_found(ip_addr const*)':
ESPAsyncTCP.cpp:(.text._ZN11AsyncClient10_dns_foundEPK7ip_addr+0xc): multiple definition of `AsyncClient::_dns_found(ip_addr const*)'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncClient10_dns_foundEPK7ip_addr+0xc): first defined here
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncClient::onConnect(std::function<void (void*, AsyncClient*)>, void*)':
ESPAsyncTCP.cpp:(.text._ZN11AsyncClient9onConnectESt8functionIFvPvPS_EES1_+0x4): multiple definition of `AsyncClient::onConnect(std::function<void (void*, AsyncClient*)>, void*)'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncClient9onConnectESt8functionIFvPvPS_EES1_+0x4): first defined here
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncClient::onDisconnect(std::function<void (void*, AsyncClient*)>, void*)':
ESPAsyncTCP.cpp:(.text._ZN11AsyncClient12onDisconnectESt8functionIFvPvPS_EES1_+0x4): multiple definition of `AsyncClient::onDisconnect(std::function<void (void*, AsyncClient*)>, void*)'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncClient12onDisconnectESt8functionIFvPvPS_EES1_+0x4): first defined here
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncClient::onPoll(std::function<void (void*, AsyncClient*)>, void*)':
ESPAsyncTCP.cpp:(.text._ZN11AsyncClient6onPollESt8functionIFvPvPS_EES1_+0x4): multiple definition of `AsyncClient::onPoll(std::function<void (void*, AsyncClient*)>, void*)'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncClient6onPollESt8functionIFvPvPS_EES1_+0x4): first defined here
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncServer::onClient(std::function<void (void*, AsyncClient*)>, void*)':
ESPAsyncTCP.cpp:(.text._ZN11AsyncServer8onClientESt8functionIFvPvP11AsyncClientEES1_+0x4): multiple definition of `AsyncServer::onClient(std::function<void (void*, AsyncClient*)>, void*)'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncServer8onClientESt8functionIFvPvP11AsyncClientEES1_+0x4): first defined here
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncClient::onAck(std::function<void (void*, AsyncClient*, unsigned int, unsigned int)>, void*)':
ESPAsyncTCP.cpp:(.text._ZN11AsyncClient5onAckESt8functionIFvPvPS_jjEES1_+0x8): multiple definition of `AsyncClient::onAck(std::function<void (void*, AsyncClient*, unsigned int, unsigned int)>, void*)'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncClient5onAckESt8functionIFvPvPS_jjEES1_+0x8): first defined here
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncClient::onData(std::function<void (void*, AsyncClient*, void*, unsigned int)>, void*)':
ESPAsyncTCP.cpp:(.text._ZN11AsyncClient6onDataESt8functionIFvPvPS_S1_jEES1_+0x8): multiple definition of `AsyncClient::onData(std::function<void (void*, AsyncClient*, void*, unsigned int)>, void*)'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncClient6onDataESt8functionIFvPvPS_S1_jEES1_+0x8): first defined here
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncClient::onPacket(std::function<void (void*, AsyncClient*, pbuf*)>, void*)':
ESPAsyncTCP.cpp:(.text._ZN11AsyncClient8onPacketESt8functionIFvPvPS_P4pbufEES1_+0x8): multiple definition of `AsyncClient::onPacket(std::function<void (void*, AsyncClient*, pbuf*)>, void*)'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncClient8onPacketESt8functionIFvPvPS_P4pbufEES1_+0x8): first defined here
.pioenvs/light_led_8/lib032/[email protected](ESPAsyncTCP.cpp.o): In function `AsyncClient::onTimeout(std::function<void (void*, AsyncClient*, unsigned int)>, void*)':
ESPAsyncTCP.cpp:(.text._ZN11AsyncClient9onTimeoutESt8functionIFvPvPS_jEES1_+0x8): multiple definition of `AsyncClient::onTimeout(std::function<void (void*, AsyncClient*, unsigned int)>, void*)'
.pioenvs/light_led_8/libfc3/libESPAsyncTCP_ID305.a(ESPAsyncTCP.cpp.o):ESPAsyncTCP.cpp:(.text._ZN11AsyncClient9onTimeoutESt8functionIFvPvPS_jEES1_+0x8): first defined here
collect2: error: ld returned 1 exit status
*** [.pioenvs/light_led_8/firmware.elf] Error 1

netsnake · 发表于 2019-10-23 10:14:20

nameryan 发表于 2019-10-22 17:49
代码和报错信息具体贴出来看看吧，话题延展一下

配置文件，很简单的，本来没错，不知为何突然开始出现！

esphome:
  name: light_led_8
  platform: ESP8266
  board: esp01_1m

wifi:
  networks:
  - ssid: !secret wifi_ssid
    password: !secret wifi_password
  - ssid: !secret wifi_ssid1
    password: !secret wifi_password

logger:

ota:
  password: !secret ota_password
api:
#  password: !secret api_password

mqtt:
  broker: !secret mqtt_broker
  username: !secret mqtt_username
  password: !secret mqtt_password
  discovery: True
  discovery_retain: true

light:
  - platform: fastled_clockless
    id: ws2812008
    chipset: WS2812
    pin: GPIO2
    num_leds: 6
    rgb_order: GRB
    name: "ws2812_8"
    effects:
      - random:
      - strobe:
      - flicker:
      - addressable_rainbow:
      - addressable_color_wipe:
      - addressable_scan:
      - addressable_twinkle:
      - addressable_random_twinkle:
      - addressable_fireworks:
      - addressable_flicker:

  - platform: fastled_clockless
    id: ws2812016
    chipset: WS2812
    pin: GPIO3 # RXD
    num_leds: 16
    rgb_order: GRB
    name: "ws2812_16"
    effects:
      - random:
      - strobe:
      - flicker:
      - addressable_rainbow:
      - addressable_color_wipe:
      - addressable_scan:
      - addressable_twinkle:
      - addressable_random_twinkle:
      - addressable_fireworks:
      - addressable_flicker:

		自动登录	找回密码
密码			立即注册

[进阶教程] ESP-01S打造的最具性价比的esphome终端

教程狂人
